Expanded Metal Flattening Machines
High-quality expanded metal flattening systems developed for precise metal processing
Available Models
TGE-75 Expanded Metal Flattening Machine
Compact flattener for thin expanded metal up to 0.80 mm
Key Features
- Ability to work both independently with plate products and integrated with expanded metal presses
- Capacity to make precise pressure adjustments on both sides
- Durable cylinder structure made of special solid steel material with special heat treatment applied
- Capacity to flatten expanded metal to its original sheet thickness
Product Description
Our machines are designed according to maximum efficiency, durability, OHS (occupational health and safety), and security values, adhering to engineering disciplines. The body of our machines is produced as steel construction and is welded by certified welders and subjected to welding tests. Raw materials are selected from certified products in accordance with Turkish and European standards. The necessary elements of our machines undergo surface hardening heat treatment and grinding processes in accordance with standards. We also provide custom designs by offering engineering solutions in line with customer requests.
Model Specifications
TGE-75 Expanded Metal Flattening Machine
Compact flattener for thin expanded metal up to 0.80 mm
| Maximum Sheet Width | 1250 mm |
| Min-Max Sheet Thickness | 0.20 mm - 0.80 mm (Expanded Metal) |
| Drive Type | Motor Reducer + Gear + Chain + Inverter |
| Power | 380 V |
| Motor | 7.5 kW |
| Cylinder Diameter | 310 mm (50 - 54 HRC) |
| Start - Stop | Automatic Switch Control |
| Weight | ≈ 2600 kg |
| Packaging Dimensions | ≈ 1050 mm x 1400 mm x 1700 mm |
All Features
Related Products
Expanded Metal Flattening Machines - Product Description
High-quality expanded metal flattening systems developed for precise metal processing
Our machines are designed according to maximum efficiency, durability, OHS (occupational health and safety), and security values, adhering to engineering disciplines. The body of our machines is produced as steel construction and is welded by certified welders and subjected to welding tests. Raw materials are selected from certified products in accordance with Turkish and European standards. The necessary elements of our machines undergo surface hardening heat treatment and grinding processes in accordance with standards. We also provide custom designs by offering engineering solutions in line with customer requests.
Key Features
- Ability to work both independently with plate products and integrated with expanded metal presses
- Capacity to make precise pressure adjustments on both sides
- Durable cylinder structure made of special solid steel material with special heat treatment applied
- Capacity to flatten expanded metal to its original sheet thickness
- Ability to process DKP, HRP, aluminum, and stainless steel materials
- Precise processing capability without damaging cylinder bands
- Model options suitable for expanded metals of different thicknesses
- Safe working system with automatic switch control
- Powerful motor capacity and durable body structure
Available Models
TGE-75 Expanded Metal Flattening Machine
Compact flattener for thin expanded metal up to 0.80 mm
Technical Specifications Maximum Sheet Width 1250 mm Min-Max Sheet Thickness 0.20 mm - 0.80 mm (Expanded Metal) Drive Type Motor Reducer + Gear + Chain + Inverter Power 380 V Motor 7.5 kW Cylinder Diameter 310 mm (50 - 54 HRC) Start - Stop Automatic Switch Control Weight ≈ 2600 kg Packaging Dimensions ≈ 1050 mm x 1400 mm x 1700 mm TGE-1000 Expanded Metal Flattening Machine
Medium-sized flattener for thin expanded metal up to 0.80 mm
Technical Specifications Maximum Sheet Width 1250 mm Min-Max Sheet Thickness 0.20 mm - 0.80 mm (Expanded Metal) Drive Type Motor Reducer + Gear + Chain + Inverter Power 380 V Motor 7.5 kW Cylinder Diameter 310 mm (50 - 54 HRC) Start - Stop Automatic Switch Control Weight ≈ 2600 kg Packaging Dimensions ≈ 1050 mm x 1400 mm x 1700 mm TGE-1250 Expanded Metal Flattening Machine
Advanced flattener for medium thickness expanded metal up to 2.00 mm
Technical Specifications Maximum Sheet Width 1250 mm Min-Max Sheet Thickness 0.40 mm - 2.00 mm (Expanded Metal) Drive Type Motor Reducer + Gear + Chain + Inverter Power 380 V Motor 7.5 kW Cylinder Diameter 310 mm (50 - 54 HRC) Start - Stop Automatic Switch Control Weight ≈ 2600 kg Packaging Dimensions ≈ 1050 mm x 1400 mm x 1700 mm TGE-1500 Expanded Metal Flattening Machine
Heavy-duty flattener for thick expanded metal up to 4.00 mm
Technical Specifications Maximum Sheet Width 1250 mm Min-Max Sheet Thickness 1.00 mm - 4.00 mm (Expanded Metal) Drive Type Motor Reducer + Gear + Chain + Inverter Power 380 V Motor 11 kW Cylinder Diameter 465 mm (50 - 54 HRC) Start - Stop Automatic Switch Control Weight ≈ 5000 kg Packaging Dimensions ≈ 1050 mm x 1400 mm x 1700 mm TGE-2000 Expanded Metal Flattening Machine
Industrial-grade flattener with 2000 mm width capacity for thick expanded metal
Technical Specifications Maximum Sheet Width 2000 mm Min-Max Sheet Thickness 1.00 mm - 4.00 mm (Expanded Metal) Drive Type Motor Reducer + Gear + Chain + Inverter Power 380 V Motor 15 kW - GAMAK Cylinder Diameter 465 mm (SOLID) Start - Stop Automatic Switch Control Weight ≈ 8000 kg Packaging Dimensions ≈ 2800 x 1800 x 2300 mm
