Perforated Sheet Press Machines
Durable and efficient perforated sheet presses developed for high-precision hole punching operations
Available Models
TPM-1250/30 Perforated Sheet Press Machine
Standard capacity perforated sheet press with 1250 mm width and 30 kW power
Key Features
- Structure suitable for both plate production and integrated production with roll strips
- Use of high-quality electronic components for optimal performance
- Easy operation capability with single operator control
- Ability to adjust production quantity and stroke values from the control screen
Product Description
Our machines are designed according to maximum efficiency, durability, OHS (occupational health and safety), and security values, adhering to engineering disciplines. The body of our machines is produced as steel construction and is welded by certified welders and subjected to welding tests. Raw materials are selected from certified products in accordance with Turkish and European standards. The necessary elements of our machines undergo surface hardening heat treatment and grinding processes in accordance with standards. Our perforated press machines, suitable for both plate production and integrated production with roll strips, also provide custom designs by offering engineering solutions in line with customer requests.
Model Specifications
TPM-1250/30 Perforated Sheet Press Machine
Standard capacity perforated sheet press with 1250 mm width and 30 kW power
| Maximum Sheet Width | 0.80 mm x 1250 mm |
| Speed (RPM) | 60 - 300 rpm |
| Stroke Distance | 40 mm |
| Power | 380 V |
| Motor | 30 kW |
| Air Clutch and Brake Mechanism | Available |
| Drive Type | Gear - Belt - Pulley - Motor |
| Speed Control | Inverter |
| Driver | 100 mm Diameter 2 drivers (1-Servo Motor) |
| Automation | PLC (7' Touch Screen) - Delta |
| Weight | ≈ 6500 kg |
All Features
Related Products
Perforated Sheet Press Machines - Product Description
Durable and efficient perforated sheet presses developed for high-precision hole punching operations
Our machines are designed according to maximum efficiency, durability, OHS (occupational health and safety), and security values, adhering to engineering disciplines. The body of our machines is produced as steel construction and is welded by certified welders and subjected to welding tests. Raw materials are selected from certified products in accordance with Turkish and European standards. The necessary elements of our machines undergo surface hardening heat treatment and grinding processes in accordance with standards. Our perforated press machines, suitable for both plate production and integrated production with roll strips, also provide custom designs by offering engineering solutions in line with customer requests.
Key Features
- Structure suitable for both plate production and integrated production with roll strips
- Use of high-quality electronic components for optimal performance
- Easy operation capability with single operator control
- Ability to adjust production quantity and stroke values from the control screen
- Adjustable speed control according to material and die requirements
- Continuous maintenance of moving machine elements with automatic lubrication system
- Long-lasting performance with hardened and ground machine elements
- Easy and precise control with PLC touch screen
- Powerful drive system with gear, belt, pulley, and motor combination
- Safe operation feature with air clutch and brake mechanism
Available Models
TPM-1250/30 Perforated Sheet Press Machine
Standard capacity perforated sheet press with 1250 mm width and 30 kW power
Technical Specifications Maximum Sheet Width 0.80 mm x 1250 mm Speed (RPM) 60 - 300 rpm Stroke Distance 40 mm Power 380 V Motor 30 kW Air Clutch and Brake Mechanism Available Drive Type Gear - Belt - Pulley - Motor Speed Control Inverter Driver 100 mm Diameter 2 drivers (1-Servo Motor) Automation PLC (7' Touch Screen) - Delta Weight ≈ 6500 kg TPM-1250/37 Perforated Sheet Press Machine
High capacity perforated sheet press with 1250 mm width and 37 kW power
Technical Specifications Maximum Sheet Width 1.5 mm x 1250 mm Speed (RPM) 60 - 250 rpm Stroke Distance 40 mm Power 380 V Motor 37 kW Air Clutch and Brake Mechanism Available Drive Type Gear - Belt - Pulley - Motor Speed Control Inverter Driver 100 mm Diameter 2 drivers (1-Servo Motor) Automation PLC (7' Touch Screen) - Delta Weight ≈ 8000 kg
